HBF series - floor type milling and boring machining center

HBF series floor type milling and boring machining center

Product features

This series of machine tools consists of a moving column and a hanging spindle box (spindle diameter) φ A side mounted layout with sliding sleepers above 200, and equipped with a CNC turntable (or floor standing platform). The X-axis of the machine tool is synchronously driven by two servo motors, precision reducers, high accuracy gears, and racks, while the other axes are driven by servo motors, precision reducers, and high accuracy Ball screws.

Mod+86 130-4748-2822

Configuration

HBF series floor type milling and boring machining centerTechnical Parameter

Project		Unit	HBF20	HBF16	HBF13
Machine range	Horizontal (X-axis) stroke of workbench	mm	5000+(N×1000)	4000+(N×1000)	4000+(N×1000)
	Vertical (Y-axis) travel of spindle box	mm	3000+(N×1000)	2500+(N×1000)	2000+(N×1000)
	Longitudinal (Z-axis) travel of the square slider	mm	1500	1200	1000
	Boring axis (W-axis) stroke	mm	1200	1000	700
Main shaft	Cross section of square slider	mm	600×650	550×600	500×550
	Boring spindle diameter	mm	φ200	φ160	φ130
	Spindle power(S1/S6)	Kw	74/93	60/90	37/54
	Boring shaft speed	rpm	10～1500	10～2000	10～2500
	Rated output torque of the spindle(S1/S6)	Nm	5196/9252	3500/5254	2500/3721
Feed	Feed Speed	m/min	X:6 Y:6 Z:4 W:4
Feed	Fast moving speed	m/min	X:10 Y:10 Z:8 W:8
accuracy	Positioning accuracy（closed loop）	mm	X/Y:0.01/1000		Z/W（semi-closed loop）:0.025
accuracy	repeatPositioning accuracy（semi-closed loop/closed loop）	mm	X/Y:0.006/1000		Z/W（semi-closed loop）: 0.02
magazine	magazine capacity	Put	32/40/60/90/120/150
	Maximum weight of cutting tools/average weight	kg	25/15
	Maximum tool size (Full blade diameter/near blade diameter x length)	mm	φ125/φ250×400
complete machine	Battery capacity	KVA	220	180	150
complete machine	Machine weight	kg	200000	140000	100000
